卷帘门门帘、导轨

Rolling shutter door curtain, guide rail

门帘：帘片材质采用钢制及铝合金双层帘片，门片采用50毫米/77毫米帘片外喷饰高强度，耐晒聚酯材料，有多种色彩可供选择，可以根据客户的需要对帘片表面饰层可作电泳饰层保护处理。

Door Curtain: The curtain material is made of steel and aluminum alloy double-layer curtain panels. The door panels are made of 50mm/77mm curtain panels and sprayed with high-strength, sun resistant polyester material. There are multiple colors to choose from, and the surface decoration layer of the curtain panels can be treated with electrophoretic coating protection according to customer needs.

导槽：材料采用铝合金制作；并可安设消音毛条，在门体运行中，几乎为超静音状态。

快盈11vGuide groove: Made of aluminum alloy material; And sound-absorbing wool strips can be installed, which are almost in a super silent state during the operation of the door body.

卷帘门主轴

Roller shutter door spindle

快盈11v我厂卷帘门主轴采用内置螺旋扭簧平衡，保持门体平衡（自重的95%左右，安装时通过调整扭簧平衡力，卷帘门门体，几近空载状态。从而也延长了电机的使用寿命。另卷筒的体积小，有利于低门头空间安装。

Our factory's roller shutter door spindle adopts a built-in spiral torsion spring balance to maintain the balance of the door body (about 95% of its own weight). During installation, by adjusting the balance force of the torsion spring, the roller shutter door body is almost in an unloaded state. This also extends the service life of the motor. In addition, the small volume of the drum is conducive to low door head space installation.

五金件

快盈11vHardware components

快盈11v我厂卷帘门五金件均为热镀锌钢板，经冲压成型制作，设计合理，尺寸准确安装方便，并可进行表面喷塑处理，以增加美观和耐腐蚀性能。

Our factory's rolling shutter door hardware is made of hot-dip galvanized steel plate, which has been stamped and formed. The design is reasonable, the size is accurate and easy to install, and the surface can be sprayed with plastic to increase aesthetics and corrosion resistance.

快盈11v驱动器（本厂自行生产）

Driver (self produced by our factory)

①、带离合器侧装式电机

① Side mounted motor with clutch

驱动器电机为大扭矩直流电机，噪音很小约在50分贝左右，比使用交流电机的管状电机噪音要小一倍以上，提升力为700N，设有行程限位装置，门体到位自停，并有遇阻反弹功能，自动延时照明功能，及停电室外应急功能，传动型式为非同轴链传动。

快盈11vThe driver motor is a high torque DC motor, with a noise level of about 50 decibels, which is more than twice the noise level of a tubular motor using an AC motor. The maximum lifting force is 700N, and it is equipped with a travel limit device. The door body is in place and automatically stops, with resistance rebound function, automatic delay lighting function, and outdoor emergency power outage function. The transmission type is non coaxial chain transmission.

②、带离合器同轴外装电机

快盈11v② Coaxial external motor with clutch

驱动器电机为大扭矩直流电机，提升力700N，设有行程限位装置，门体到位自停，并有遇阻反弹功能，及停电室外应急功能，可加装延时照明功能。

The drive motor is a high torque DC motor with a maximum lifting force of 700N. It is equipped with a travel limit device, and the door body stops automatically when it is in place. It also has a rebound function when encountering obstacles, as well as an outdoor emergency function for power outages. Delayed lighting function can be added.

快盈11v③、带离合器同轴内装电机

快盈11v③ Coaxial built-in motor with clutch

性能与上相同，电机安装于卷筒内，同轴安装。

The performance is the same as above, and the motor is installed inside the drum and coaxial.

操作方便：

快盈11vEasy to operate:

快盈11v可采用遥控操作的按钮操作，到位自动停止，限位精度高。电机带有离合器装置，停电时，通过拉动离合器释放钢丝绳，即可轻松转入手动状态。同样，通过拉动该钢丝绳，亦可转入锁定状态，可在任意位置锁定门体，操作十分方便。

It can be operated by remote control buttons, automatically stopping when in place, and has high limit accuracy. The motor is equipped with a clutch device. When there is a power outage, it can easily switch to manual mode by pulling the clutch to release the steel wire rope. Similarly, by pulling the steel wire rope, the door can also be locked in any position, making the operation very convenient.

升级功能：

Upgrade function:

理想牌侧装电机，留有多个接口，可根据用户的需要加设

Ideal brand side mounted motor with multiple interfaces, which can be added according to user needs

快盈11v储电功能/红外线保护装置/气囊装置等。

Energy storage function/infrared safety protection device/safety airbag device, etc.

快盈11v四、卷帘门的基本配置：

快盈11v4、 Basic configuration of rolling shutter doors:

卷帘片；主轴；驱动器系统一套（包含遥控器贰只、及停电应急锁一把钥匙贰）；

Rolling shutter sheet; Spindle; One set of drive system (including two remote controllers and one key for power outage emergency lock);
