With the development of science and technology, electric rolling shutter door also has a new breakthrough. The use of remote control of electric rolling gate replaces the original manual button, which is suitable for remote control of rolling shutter door, telescopic door, curtain, etc. As the name implies, the remote control of electric rolling shutter corresponds to the electric rolling shutter, which can control the rolling shutter to close or put down. Some remote controllers of rolling gate also have the function of locking. The remote controller of rolling gate can be roughly divided into radio type and infrared type. Like the general remote controller, the rolling gate remote controller is also divided into two parts: transmitting and receiving. According to different security requirements, different levels of coding are adopted. For the friends who have this demand, I would like to know how to use the remote control of electric rolling gate! Don't worry, now I'll explain the use of the remote control of the electric rolling gate, the common faults and solutions of the remote control of the electric rolling gate, hoping to help you.

1.电动机不动或转速慢——故障原因一般是线路断路、电机烧损、停止按钮没复位、限位开关动作、负载较大等引起。

1. The motor does not move or the speed is slow - the fault reasons are generally caused by circuit break, motor burning, stop button not reset, limit switch action, heavy load, etc.

处理方法：检查线路、并接通；更换烧损电机；更换按钮或重复按动几次； 拨动限位开关滑块使它脱离微动开关触点， 并调整微动开关位置；检查机械部分 有无卡阻，若有则卡阻清理障碍物。

Treatment method: check the circuit and connect it; replace the burned motor; replace the button or press it repeatedly; move the slide of the limit switch to make it separate from the contact of the microswitch, and adjust the position of the microswitch; check whether the mechanical part is jammed, if any, eliminate the jam and clear the obstacles.

2.控制失效——故障发生的部位及原因：.继电器（接触器）触点粘死、行程微动开关失效 或触片变形、滑块紧定螺钉松、靠板螺丝松使靠板移位，使滑块或螺母不能随丝 杆转动而移动、限位器传动齿轮破损、按钮上、下键卡死。

2. Control failure the position and cause of the failure: the contact of relay (contactor) is stuck, the travel microswitch fails or the contact piece is deformed, the locking screw of slide block is loose, the screw of backup plate is loose, so that the slider or nut can not move with the screw rod rotation, the transmission gear of the limiter is damaged, and the up and down keys of the button are stuck.

处理方法：更换继电器（接触器）；更换微动开关或触片；紧定滑块螺钉并 使靠板复位；更换限位器传动齿轮；更换按钮。

Treatment methods: replace the relay (contactor); replace the microswitch or contact piece; tighten the slider screw and reset the backup plate; replace the transmission gear of the limiter; replace the button.

3.手拉链不动——故障原因：环形链条堵住十字槽；棘爪无脱离棘轮；压链架卡死。

3. The hand zipper does not move - the fault causes: the ring chain blocks the cross groove; the pawl does not separate from the ratchet wheel; the chain holder is stuck.

处理方法：理顺环形链条；调整棘爪与压链架相对位置；更换或润滑销轴。

Treatment method: straighten out the ring chain; adjust the relative position between the pawl and the chain holder; replace or lubricate the pin shaft.

4.电机振动或噪声较大——故障原因：刹车盘不平衡或断裂；刹车盘无紧固；轴承失油或失效；齿轮啮合不顺、失油或磨损严重；电机电流声或振动.

4. High motor vibration or noise - fault causes: brake disc imbalance or fracture; brake disc is not fastened; bearing oil loss or failure; gear meshing is not smooth, oil loss or serious wear; motor current sound or vibration

处理方法：更换刹车盘或重新调整平衡；紧固刹车盘螺母；更换轴承；修配电机轴输出端齿轮、润滑或更换；检查电机，如电机坏损则更换。

Treatment methods: replace the brake disc or readjust the balance; tighten the brake disc nut; replace the bearing; repair the motor shaft output gear, lubrication or replacement; check the motor, if the motor is damaged, replace it.

5.检查电动卷闸门的支位偏差及螺丝松紧情况，检查皮带的松紧情况，检查控制器对电机输出清洁机箱内部的油污、 灰尘检查自动电动门各部件的磨损情况高速门，开关门宽度、速度、制动等情况检查电压参数是否正常维修、更换损坏的部件业主还需注重自动门的定期保养与维护，自动门由于受安装质量及使用环境的影响，使用过程中难免会发生问题。

5. Check the support deviation and screw tightness of the electric rolling gate, check the tightness of the belt, check the output of the controller to the motor, and clean the oil stain inside the cabinet Dust inspection automatic electric door parts wear, high-speed door, door opening and closing width, speed, braking, etc. check whether the voltage parameters are normal, repair and replace the damaged parts. The owner also needs to pay attention to the regular maintenance and maintenance of the automatic door. Due to the influence of installation quality and use environment, problems will inevitably occur in the use process of automatic door.

6.如果长期缺乏保养，导致电动卷闸门存在的隐患及小故障得不到及时处理，马达得到一定运行电流后做正向运行， 将动力传给同步带， 再由同步带将动力传给吊具系统使门扇 开启；门扇开启后由控制器作出判断，如需关门，通知马达作反向运动，关闭门扇。将会由 小故障变成大故障，更终可能导致自动电动门的瘫痪。感应探测器探测到有人进入时，将 脉冲信号传给主控器，主控器判断后通知马达运行，同时监控马达转数，以便通知马达在一定时候加力和进入慢行运行。

6. If there is a long-term lack of maintenance, resulting in hidden dangers and small faults of the electric rolling gate can not be handled in time, the motor will run forward after getting a certain running current, and then the power will be transmitted to the synchronous belt by the synchronous belt, and then the power will be transmitted to the spreader system by the synchronous belt to open the door leaf; after the door leaf is opened, the controller will make a judgment, and if it is necessary to close the door, the motor will be informed to move backward and close the door leaf. It will change from a small fault to a big fault, which may eventually lead to the paralysis of the automatic electric door. When the induction detector detects that someone enters, the pulse signal will be transmitted to the main controller. After the master controller judges, it will inform the motor to run, and at the same time monitor the motor speed, so as to inform the motor to increase force and enter into slow running at a certain time.

7.内部的流动性。你可能需要安装电动卷闸门终结一个或多个室内门以及。操作人员应随时留视伸缩门门体运行情况，以免发生意外。轨道内应经常清扫，以免杂物堆积影响运行。

7. Internal liquidity. You may need to install an electric roll gate to terminate one or more interior doors as well. The operator should keep an eye on the operation of the telescopic door at any time to avoid accidents. The track should be cleaned regularly to avoid the accumulation of debris affecting the operation.

8.驱动器每年少要加注一次润滑脂，链条应经常加注润滑油，并检查各部件磨损情况，磨损严重的机件要及时维修或更换。

8. The driver should be filled with grease at least once a year, the chain should be filled with lubricating oil frequently, and the wear condition of each component should be checked. The seriously worn parts should be repaired or replaced in time.

以上就是电动卷闸门遥控器使用方法，常见的电动卷闸门遥控器故障及处理方法的相关介绍，希望能够帮助到有这方面需求的朋友们！如需了解更多的相关资讯，请继续关注我们网站。后续将呈现更多精彩内容哦！

The above is the use of electric roller shutter remote control, common electric roller shutter remote control failure and treatment methods related to the introduction, I hope to help friends with this demand! For more information, please follow our website. More wonderful content will be presented later!
