电动卷帘门在安装时要注意几个要点
来源:http://xl0475.com 日期:2023-01-28 发布人:
电动卷帘门是一种安装在许多公共场所的门,广泛应用于各种商店立面的装饰。安装时应有专门的施工人员根据现场实际情况进行安装调试。今天济南卷帘门厂家来给大家说一下电动卷帘门在安装时要注意几个要点。
Electric roller shutter door is a kind of door installed in many public places and widely used in the decoration of various store facades. During the installation, special construction personnel shall carry out the installation and commissioning according to the actual situation on the site. Today, Jinan roller shutter door manufacturer will tell you a few key points to pay attention to when installing the electric roller shutter door.
(1)按设计型号,查阅产品说明书,检查产品表面处理和零附件。
(1) According to the design model, consult the product manual, and check the product surface treatment and accessories.
(2)测量产品各部位基本尺寸,检查门洞口是否与卷帘门尺寸相符,导轨、支架埋件位置、数量是否正确。
(2) Measure the basic dimensions of each part of the product, check whether the door opening is consistent with the size of the rolling shutter door, and whether the position and quantity of the embedded parts of the guide rail and bracket are correct.
(3)测量洞口标高,弹出两导轨垂线及卷筒线。
(3) Measure the elevation of the hole and snap the vertical line of the two guide rails and the center line of the drum.
(4)将垫板电焊在预埋铁板上,用螺丝固定卷筒的左右支架,安装卷筒。卷筒安装后应转动灵活。
(4) Weld the base plate on the embedded iron plate, fix the left and right supports of the drum with screws, and install the drum. The drum shall rotate flexibly after installation.
(5)安装减速器和传动系统;安裳电气拴街系统;空载试车。
(5) Install the reducer and transmission system; Anshang electric street system; No-load test run.
(6)先用手去试运行,再用电动机启闭数次,调整无卡住、阻滞及异常。
(6) First, use your hand to test run, then start and close the motor several times, and adjust it to be free of jamming, blocking and abnormality.
卷帘门帘片穿好后,要将两边用封头给封好,然后用拉铆钉将其拉住,在一边对帘子进行打孔一边用绳拴住,接着在用镙丝杆将帘子和轴紧密连在一起,后将卷帘门的帘子进行调平处理,以保证卷帘门使用的合理性。然后在将卷帘门来回的上升及下降,以检测其的安装质量及。更多相关的内容就来我们网站http://xl0475.com咨询!
After the roller shutter is put in place, both sides shall be sealed with heads, and then pulled with rivets. The curtain shall be punched at one side and tied with ropes. Then the curtain and shaft shall be tightly connected with screw rods, and then the curtain of the roller shutter shall be leveled to ensure the safety and rationality of the roller shutter. Then raise and lower the shutter door back and forth to check its installation quality and safety. Come to our website for more relevant content http://xl0475.com consulting service
