　　工业门：通常指用于厂房和其他工业建筑场合，供人员或车辆通行的大门，一般门扇面积和重量较大，性要求更高。



　　Industrial door:it usually refers to the door used in factories and other industrial buildings for the passage of personnel or vehicles.Generally,the door leaf area and weight are larger and the safety requirements are higher.



　　安装方式：门扇通过导轨向上运动的工业门的安装方式。



　　Installation method:the installation method of industrial door whose door leaf moves upward through guide rail.



　　分节上翻式：直门扇通过导轨向上并有分段转向运动的工业门的安装方式。



　　Sectional upturning type:the installation method of industrial door with straight door leaf upward through guide rail and sectional steering movement.



　　垂直提升式：指门扇通过导航整体垂直向上运动的工业门的安装方式。



　　Vertical lifting type:refers to the installation mode of industrial door whose door leaf moves vertically upward through navigation.



　　分层垂直提升式：若干块门扇前后叠放，通过导轨和传动系统使其分层次垂直上下运动的工业门的安装方式。



　　Layered vertical lifting type:the installation mode of industrial doors in which several door leaves are stacked back and forth and move vertically up and down in layers through guide rails and transmission system.



　　常规安装方式：指不需采取特殊措施，左右侧安装的横轨均为单根即能正常运行的分节上翻式工业门的安装方式，主要适用于门楣高度不小于600mm的洞口。



　　Conventional installation method:it refers to the installation method of sectional upturned industrial door,which can operate normally without special measures,and the transverse rails installed on the left and right sides are single.It is mainly applicable to openings with a lintel height of no less than 600mm.



　　高位提升式：指门扇通过导轨垂直向上运行一段后再分段转向运动的分节上翻式工业门的安装方式。



　　High lift type:refers to the installation mode of sectional upturned industrial door in which the door leaf runs vertically upward through the guide rail for a period and then turns in sections.



　　顶置安装方式：扭簧平衡系统位于完全开启的门扇顶部的垂直提升式工业门的安装方式。中置粱安装方式：扭簧平衡系统位于完全开启的门扇的部位的垂直提升式工业门的安装方式。



　　Overhead installation mode:the installation mode of vertical lifting industrial door with torsion spring balance system on the top of fully open door leaf.Installation method of central beam:the installation method of vertical lifting industrial door with torsion spring balance system located in the central part of fully open door leaf.



　　配重平衡方式：采用配重方式来平衡门扇重量的垂直提升式工业门的安装方式。



　　Counterweight balance mode:the installation mode of vertical lifting industrial door that uses counterweight to balance the weight of door leaf.



　　推拉式：通过导轨和传动系统使门扇向左右方向推拉的工业门的安装方式。



　　Push-pull type:the installation mode of industrial door that pushes and pulls the door leaf to the left and right through the guide rail and transmission system.



　　上承重式：指门扇重量由门扇顶部导轨来承受的推拉式工业门的安装方式。



　　Upper bearing type:refers to the installation method of push-pull industrial door whose weight is borne by the guide rail at the top of the door leaf.



　　下承重式：指门扇重量由门扇下部的地轨来承受的推拉式工业门的安装方式。



　　Lower bearing type:refers to the installation method of push-pull industrial door whose weight is borne by the ground rail at the lower part of the door leaf.



　　下承重电机固定式：直开门机固定位置的下承重式工业门的安装方式。



　　Fixed type of lower load-bearing motor:the installation method of lower load-bearing industrial door at the fixed position of straight door opener.



　　下承重电机随动式：指开门机安装在门扇上随门扇运动的下承重式工业门的安装方式。



　　Lower load-bearing motor follow-up type:refers to the installation mode of lower load-bearing industrial door in which the door opener is installed on the door leaf and moves with the door leaf.



　　推拉折叠式：指多快门板通过铰链连接、开启过程中相领门板逐步折叠起来的推拉式工业门的安装方式。



　　Push-pull folding type:refers to the installation mode of push-pull industrial door in which multiple shutter plates are connected through hinges and the leading door plate is gradually folded during the opening process.



　　侧滑式：指借助于导轨，吊轮沿墙面作侧向滑移，并在一侧门垛处作转向运动的工业门的安装方式。



　　Side sliding type:refers to the installation mode of industrial door with the help of guide rail,the lifting wheel slides laterally along the wall and makes steering movement at one side of the door stack.



　　卷帘式：通过卷轴或卷筒转动带动帘片式门扇运动、从而实现门扇启闭的工业门的安装方式。整板工业卷帘门：是有高强度彩涂钢板扎制成型的整板门扇、扭簧平衡系统和导正消音系统等组合而成的工业卷门，相对卷帘式车库门而言，一般门扇面积和重量较大，性要求更高。双层帘片式工业卷门：指帘片式门扇是由铝合金型材或钢制型材，具内部填充隔声、保温材料制成的工业卷门。



　　Rolling shutter type:the installation mode of industrial door that drives the movement of curtain leaf through the rotation of reel or drum,so as to realize the opening and closing of door leaf.Whole plate industrial rolling shutter door:it is an industrial rolling door composed of high-strength color coated steel plate,torsion spring balance system and positive silencing system.Compared with rolling shutter garage door,the general door leaf has larger area and weight and higher safety requirements.Double layer curtain type industrial rolling door:refers to the industrial rolling door whose curtain type door leaf is made of aluminum alloy profile or steel profile and is internally filled with sound insulation and thermal insulation materials.



　　2）、专用配件



　　2).special accessories



　　缓冲助推器：安装在导轨末端，实现门扇到位时的缓冲和启动时的助推功能的机构。



　　Buffer booster:a mechanism installed at the end of the guide rail to realize the buffer function when the door leaf is in place and the boost function when starting.



　　门中门（小门）：指在较大的工业门中，为方便人员通行在大门门扇中开设的小门。



　　Door in door(small door):refers to the small door opened in the door leaf of the gate in order to facilitate the passage of personnel in the larger industrial door.



　　采光窗：为增强室内光线而在门扇上开设的透明窗户。



　　Daylighting window:a transparent window opened on the door leaf to enhance indoor light.



　　平轮：指形状为柱型，适于常规安装方式和低空安装方式用的钢丝绳轮。



　　Flat wheel:refers to the steel wire rope wheel with column shape and suitable for conventional installation and low altitude installation.



　　塔轮：指形状似塔型，适于垂直提升式工业门用的钢丝绳轮。



　　Tower pulley:refers to the steel wire rope pulley which is shaped like a tower and suitable for vertical lifting industrial doors.



　　半塔轮：指形状一部分为柱型、一部分为塔型，适于高位提升式工业门用的钢丝绳轮。



　　Half tower wheel:refers to the steel wire rope wheel whose shape is part of column type and part of tower type,which is suitable for high-level lifting industrial door.



　　联轴器：将的扭簧轴连接起来，实现同步转动的结构件。



　　Coupling:a structural member that connects the torsion spring shaft to realize synchronous rotation.



　　钢丝绳断裂保护器：指在上滑道门系统中的钢丝绳断裂时，能迅速防止门扇向下滑行的保护装置。



　　Wire rope breaking protector:refers to the safety protection device that can quickly prevent the door leaf from sliding downward when the wire rope in the upper sliding door system is broken.



　　扭簧防断裂保护器：指在上滑道门平衡系统中的扭簧断裂时，能迅速防止扭簧轴运动，实现组织门扇向下滑行的保护装置。



　　Torsion spring anti fracture Protector:refers to a safety protection device that can quickly prevent the movement of torsion spring shaft and organize the door leaf to slide downward when the torsion spring in the upper sliding door balance system is broken.
